A unique combination of safety, efficiency, and comfort with the thinnest design in its class.
Interra DALI Presence Sensor is a multi-functional device suitable for indoor usages with high bay detection capability.
It contains four different types of instances compatible with DALI standards. These instances are as follows:
0; Pushbutton,
1; Pushbutton,
2; Absolute Input,
3; Absolute Input,
4; Occupancy Sensor,
5; Light Sensor.
It can measure dry contact inputs via Push Buttons, internal and external temperature values via Absolute inputs, presence in the environment via the Occupancy Sensor, and ambient light level via the
Light Sensor. Temperature measurements can be made via an integrated temperature sensor and temperature information can be reported to DALI bus.
Main Functions:
• Supports presence detection, brightness detection, movement detection, and internal and external temperature detection
• Presence detection, based on a passive infrared sensor
• External devices can be connected via 2 digital inputs and 1 analog input. Digital inputs are used for Push-Buttons and analog input is used for the external temperature sensors.
• Every instance can transmit events to inform another bus unit. It is possible to disable events if we aren't interested in the event.
